Bolt circle of caravans with Al-Ko chassis
Our caravans produced up to model year 2000 have factory-fitted rims with a bolt circle of 4 x 100. From model year 2000 onwards, rims with a bolt circle of 5 x 112 were fitted at the factory.
Note: In the event of a possible increase of load capacity (caravans up to model year 2000) with technical modifications (axle replacement), care should be taken to ensure that other rims may also be required.
Bolt circle motorhomes with light and maxi chassis
Our motorhomes, which are produced with a light chassis, are fitted with rims with a bolt circle of 5 x 118 at the factory.
Exception: Motorhomes produced with a light chassis and the optional equipment "Automatic transmission" are fitted with rims with a bolt circle of 5 x 130 at the factory.
Our motorhomes, which are produced with a Maxi chassis, are fitted with rims with a bolt circle of 5 x 130 at the factory.
Bolt circle motorhomes with Iveco Daily chassis
Our motorhomes, which are produced with an Iveco Daily chassis, are fitted with rims with a bolt circle of 6 x 170 at the factory.
